dB Technologies IS26T Black

dB Technologies IS26T Black

IS26T is equipped with two times 6.5" woofers plus a 1" compression driver for the higher end.
2 different coverage options are available, with the two different coverage options providing respectively 60 x90° or a 100x15° dispersion pattern, which basically, thanks to a waveguide, is turning the point source speaker into a line array.
You can either fly, or stack arrays with the very same accessories you would use with the VIO X206.
Needless to say the keyword here is: ease of installation and unobtrusiveness. That's why each single system in IS series comes with a smooth design with few invisible pin points, Phoenix connectors, black or white version.

Technical Data

• Speaker Type: Passive 2-way Speaker
• RMS Power: 250 W
• Peak Power: 1000 W
• Frequency Response [-6 dB]: 80 Hz - 20,000 Hz
• Impedance: 8 Ohm
• Max SPL: 124 dB
• HF: 1x 1", 1.7" v.c.
• LF: 2x 6.5", 1.7" v.c.
• Dispersion: 60x90° [rotatable horn]
• X-Over Frequency: 1200 Hz (internal X-Over)
• Input Connections: Phoenix
• Housing: Plywood, water-painted coating
• Rigging points: 2x M10 threaded nut (top and bottom)
• IP rating: IP 32
• Width: 210 mm
• Height: 650 mm
• Depth: 270 mm
• Weight: 15.5 kg
